Square Drive - XTS Series
The XTORC XTS Series is precision-engineered to deliver unmatched performance in the most demanding bolting environments. Designed for reliability, accuracy, and ease of use, the XTS Series ensures consistent torque output across every application — whether in wind, oil & gas, power generation, or heavy engineering industries. Crafted from high-strength aerospace-grade alloy, the XTS wrench combines superior durability with lightweight handling. Its advanced hydraulic mechanism and leak-free swivel design ensure smooth, efficient, and safe operation even under extreme conditions.
Key Highlights:
- Compatible with all standard impact sockets — no special attachments required
- Aerospace-grade alloy body for exceptional strength and fatigue resistance
- Dual-direction torque application for both tightening and loosening operations
- 360° × 180° hose swivel design for maximum accessibility in confined spaces
- Precision-engineered seals ensure zero oil leaks and long service life
- Delivers torque up to 70,000 Nm with ±3% repeatability
Technical Specifications
| Unit | XTS-07 | XTS-1 | XTS-3 | XTS-5 | XTS-8 | XTS-10 | XTS-20 | XTS-25 | XTS-35 | XTS-50 | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Sq. Drive | inch | 3/4" | 3/4" | 1" | 1.1/2" | 1.1/2" | 1.1/2" | 2.1/2" | 2.1/2" | 2.1/2" | 2.1/2" |
| Min. Torque | Nm | 112 | 172 | 450 | 740 | 1078 | 1450 | 2719 | 3472 | 4866 | 6925 |
| Max. Torque | Nm | 1120 | 1731 | 4500 | 7380 | 10780 | 14508 | 27197 | 34725 | 48666 | 69247 |
| Bolt Size | mm | 14-30 | 16-36 | 22-48 | 27-56 | 30-64 | 36-72 | 42-90 | 48-100 | 64-120 | 72-125 |
| Weight | Kg | 1.8 | 2.5 | 4.9 | 9.5 | 10.8 | 14.7 | 26 | 35 | 50 | 65 |
Dimensional Data
| Unit | XTS-07 | XTS-1 | XTS-3 | XTS-5 | XTS-8 | XTS-10 | XTS-20 | XTS-25 | XTS-35 | XTS-50 | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Body Length (L1) | mm | 110 | 144.5 | 178 | 213 | 222 | 246 | 305 | 321 | 371 | 376 |
| Body Length (L1) | inch | 4.33 | 5.69 | 7.0 | 8.38 | 8.74 | 9.69 | 12.0 | 12.6 | 14.6 | 14.8 |
| Overall Length (L2) | mm | 139 | 173 | 228 | 274.5 | 292 | 317 | 383 | 401 | 465 | 528 |
| Overall Length (L2) | inch | 5.47 | 6.81 | 8.98 | 10.80 | 11.49 | 12.48 | 15.08 | 15.78 | 18.3 | 20.78 |
| Tool Width (H1) | mm | 42 | 52 | 69.5 | 82.5 | 92 | 102 | 112.5 | 120 | 137 | 162 |
| Tool Width (H1) | inch | 1.65 | 2.04 | 2.74 | 3.24 | 3.62 | 4.01 | 4.43 | 4.72 | 5.39 | 6.14 |
| Overall Width (H2) | mm | 65 | 75 | 94 | 128.5 | 134 | 142 | 183 | 200 | 216 | 226 |
| Overall Width (H2) | inch | 2.55 | 2.95 | 3.7 | 5.06 | 5.2 | 5.6 | 7.2 | 7.87 | 8.5 | 8.9 |
| Tool Height (H3) | mm | 77 | 95.5 | 115 | 149 | 167 | 182 | 220 | 246 | 282 | 291 |
| Tool Height (H3) | inch | 3.03 | 3.76 | 4.53 | 5.87 | 6.57 | 7.16 | 8.33 | 9.68 | 11.1 | 11.5 |
| Overall Height (H4) | mm | 108 | 136 | 176 | 199 | 217 | 232 | 270 | 297 | 332 | 226 |
| Overall Height (H4) | inch | 4.25 | 5.35 | 6.93 | 7.83 | 8.54 | 9.13 | 10.62 | 11.69 | 13.07 | 12.83 |
| Tool Radius Around Bolt (R1) | mm | 21 | 26.3 | 34.5 | 39 | 47 | 51 | 59 | 66 | 77 | 78.8 |
| Tool Radius Around Bolt (R1) | inch | 0.82 | 1.03 | 1.36 | 1.53 | 1.85 | 2 | 2.32 | 2.59 | 3.03 | 3.1 |
| Reaction Reach (R2) | mm | 68 | 85 | 111.5 | 140 | 153 | 154 | 186 | 199 | 241 | 295 |
| Reaction Reach (R2) | inch | 2.67 | 3.35 | 4.39 | 5.51 | 6.02 | 6.06 | 7.32 | 7.83 | 9.48 | 11.6 |
