Hydraulic Nut Splitters
XTORC's Light Weight Hydraulic Nut Splitters are used in applications that involve corrosion; it can be used to remove corroded or seized nuts fast and safely. The light weight option helps the user to apply the product to lower sized bolts.
XTORC's offers Weight Hydraulic Nut Splitters for a range of Hex size 0.37" to 2.95". Our product is designed for operator comfort that fits tight spaces and it cuts through the hardest of nuts.
Application:
- •The fast, sure and safe method to cut and remove seized nuts
- •Compact and ergonomic angled head design
- •Heavy duty cutting tool, can be re-ground
- •Designed for Operator comfort, fits tight spaces, removes corroded or frozen nuts faster and safely, and cuts through the hardest of nuts.
Nut Splitter is supplied complete with:
- •Hydraulic Cylinder
- •Housing
- •Chisel
- •Set of Allen Keys Spacer Set
- •Packed in a Rugged Steel Tool Box
Technical Specifications - XNSL Series
| Model | Hex Size | Thread Size | A in(mm) | B in(mm) | C in(mm) | D in(mm) | E in(mm) | F in(mm) | Weight lbs(kg) | Replacement Chisel Model Nos. | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | |||||||||||
| XNSL-5 | 0.37"-0.75" (10-19) | M6-M12 | 1.57" (40) | 2.04" (52) | 0.31" (8) | 0.79" (20) | 5.11" (130) | 1.18" (30) | 2 (1) | TNSC-5 | ||
| XNSL-10 | 0.75"-0.94" (19-24) | M12-M16 | 2.12" (54) | 2.64" (67) | 0.47" (12) | 0.94" (24) | 6.41" (163) | 1.41" (41) | 4 (2) | TNSC-10 | ||
| XNSL-15 | 0.94"-1.26" (24-32) | M16-M22 | 2.52" (64) | 3.11" (79) | 0.51" (13) | 1.18" (30) | 7.36" (187) | 2.04" (52) | 6 (3) | TNSC-15 | ||
| XNSL-20 | 1.26"-1.61" (32-41) | M22-M27 | 3.07" (78) | 3.70" (94) | 0.78" (20) | 1.46" (37) | 8.62" (219) | 2.72" (69) | 10 (4.5) | TNSC-20 | ||
| XNSL-35 | 1.61"-1.97" (41-50) | M27-M33 | 3.74" (95) | 4.45" (113) | 0.83" (21) | 1.77" (45) | 10.43" (265) | 3.07" (78) | 21 (9.6) | TNSC-35 | ||
| XNSL-50 | 1.97"-2.36" (50-60) | M33-M39 | 4.17" (106) | 5.04" (128) | 0.98" (25) | 2.12" (54) | 11.69" (297) | 3.58" (91) | 29 (13) | TNSC-50 | ||
| XNSL-90 | 2.36"-2.95" (60-75) | M39-M48 | 6.14" (156) | 7.28" (185) | 1.06" (27) | 2.95" (75) | 14.05" (357) | 4.33" (110) | 75 (34) | TNSC-90 | ||
Higher capacity and customized solutions on request. Specifications are subject to change due to continual improvement.
Technical Specifications - XNSH Series
| Model | Stud Diameter | Nut A/F | A in(mm) | B in(mm) | C in(mm) | D in(mm) | E in(mm) | F in(mm) | Weight lbs(kg) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | in | mm | ||||||||
| XNSH 105 | 7/16"-7/8" | 11-22 | 5/8"-17/16" | 16-36 | 11" (271) | 1.05" (38) | 1.49" (38) | 4.13" (105) | 60 | 0.39" (10) | 20 (9) |
| XNSH 200 | 7/8"-11/4" | 22-31 | 15/16"-2" | 33-50 | 11.29" (287) | 1.05" (38) | 2.12" (54) | 4.25" (108) | 45 | 0.51" (13) | 21 (10) |
| XNSH 204 | 11/4"-11/2" | 32-38 | 17/8"-23/8" | 47-60 | 15.16" (385) | 2 1/4" (57) | 2.52" (64) | 6.45" (164) | 30 | 0.55" (14) | 71 (32) |
| XNSH 210 | 13/8"-13/4" | 39-44 | 21/16"-23/4" | 52-70 | 16.10" (398) | 2 1/4" (57) | 2.87" (73) | 6.45" (164) | 30 | 0.70" (18) | 72 (33) |
| XNSH 308 | 1.3/4"-2.1/4" | 45-57 | 2.5/8"-3.1/2" | 70-89 | 17.75" (460) | 3" (77.8) | 3.89" (99) | 8.42" (214) | 30 | 0.75" (19) | 158 (72) |
| XNSH 314 | 2"-2.1/2" | 50-64 | 3.1/8"-3.7/8" | 79-98 | 18" (488) | 3.12" (79.4) | 4.25" (108) | 8.42" (214) | 30 | 0.86" (22.2) | 163 (74) |
| XNSH 404 | 2.1/2"-2.3/4" | 64-70 | 3.3/4"-4.1/4" | 95-108 | 22.75" (579) | 3.75" (95.3) | 4.64" (118) | 9.88" (251) | 60 | 1.14" (28.6) | 251 (114) |
| XNSH 500 | 3"-3.1/4" | 76-83 | 4.1/2"-5" | 114-127 | 18" (488) | 4.12" (104.8) | 5.37" (137) | 9.88" (251) | 60 | 1.14" (28.6) | 256 (116) |
| XNSH 506 | 3.1/4"-3.1/2" | 83-89 | 4.7/8"-5.3/8" | 124-136 | 23.5" (598) | 4.12" (104.8) | 5.86" (149) | 9.88" (251) | 60 | 1.14" (28.6) | 262 (119) |
